CAD Files
Vitrabond FR (MCM / Aluminum Cladding Material): Arrowhead Lean System
Arrowhead Lean takes all the benefits of our more traditional Arrowhead Flex system and adds an extremely simplified fabrication process.
Arrowhead lean offers a faster and more efficient fabrication process without the need for exposed fasteners.
Non progressive installation method, like Flex and Flush allows contractors to work around trades.
Panel assembly and fabrication is made significantly faster by eliminating need to fasten the material to the extrusion.
No exposed fasteners provide a clean and simple aesthetic.
Vitrabond FR (MCM / Aluminum Cladding Material): Arrowhead Flex Panel System
Arrowhead Flex is aesthetically similar to traditional rainscreen systems, but is designed to significantly reduce installation time and labor costs
Non progressive design allows installers to start and stop as needed, use multiple crews on a single elevation, and work around other trades.
Fully tested to AAMA 508 and 509 Florida Product Approval, and multiple ASTM Approvals.
Fast and easy installation with revolutionary Arrowhead t-clip.
Fairview offers a comprehensive training program taught by our panel consultants for both fabrication and installation.
Arrowhead Flex provide design flexibility by offering the ability to vary panel depth with the same simple installation process.
Vitrabond FR (MCM / Aluminum Cladding Material): Arrowhead Flush Panel System
Arrowhead Flush, like Lean and Flex is also a non progressive system but features a unique aesthetic This system provides a minimalistic look with shallow reveals and easy fabrication.
Shallow reveal depth provides clean and minimalistic look.
Easy fabrication and installation just like Flex and Lean.
Easily remove and replace panels without affecting panels around it.
Specification Files
Vitrabond & Vitraplate Specifications
Fairview Architectural: Leaders in Façade Innovation and Safety
For over a decade, Fairview Architectural has been at the forefront of façade innovation and safety. Our solution-driven approach has resulted in industry-leading capabilities, including unlimited color matching, Vitranar® flexible resin coatings, revolutionary Arrowhead® Installation Systems, and prefinished Vitraplate®. We ensure facades endure for decades.
RapidWrapCI® Continuous Insulation System
RapidWrapCI® is a Continuous Insulation System that has been designed to ensure that it wraps around a building reducing thermal bridging. This means that RapidWrapCI® can improve the thermal performance and energy efficiency of any construction project whilst also retaining the installation benefits of our Arrowhead panel installation system.
RapidWrapCI® is a fully-tested (NFPA-285 and ASHRAE 90.1) approved system that provides thermal performance benefits as well as having passed the large scale fire test. The wall build-up consists of Arrowhead® installation systems (FLEX & LEAN) combined with polyiso compliant insulation such as DuPont’s Thermax and the option of using Vitrabond FR® or Vitraplate® cladding panels.
RapidWrapCI® enables you to specify a fully-tested compliant system instead of needing to specify each individual component separately.
